Every digital camera has a White Balance or Automatic White Balance (AWB) setting in the camera menu. But how many of us actually use it or even know what it is for? Fortunately, most manufacturers have the Automatic White Balance pre-set in their cameras when they are shipped out. So most consumers are using it even if they are not aware of it.
What is the purpose of White Balance?
Sometimes when we take a picture, the overall color tint of the image might be yellowish, blueish, or something in between. In any case, that overcast tint was not visible when the picture was taken and many times it can ruin a very good image.
The purpose of white balance is to eliminate the discoloration in an image due to certain colors in the scene having more intensity and/or a higher or lower “temperature”.
Thats right…colors in a scene have temperatures. Blue light has a high color temperature and red light has a low color temperature. Don’t look at these temperatures as hot or cold as in when we touch something. Rather, look at it as a measurement of the intensity of the light. The intensity of the light is measured by what is called the Kelvin scale. See the examples below.
Source of Light Color Temperature
- Tungsten/Incandescent Light 2.500-3,000 K (Kelvin)
- Clear Day (Mid day outside) 5,000-6,500 K
- Shade or Heavily overcast day 9,000-10,000 K
These are very approximately values. As you can see, a tungsten light (regular light bulb) has a pretty cool color temperature. Its color temperature is closer to the red side of the color spectrum. If you take a picture with a lightbulb as the only light source, the image will have a slight orange /yellowish tint. (a red tint would be the extreme but the lightbulb temperature is not that cool). On the other hand a picture taken in the shade or on an overcast day might have a slightly bluish tint since the much higher temperature is closer to the other side of the color spectrum.
What does temperature have to do with White Balance?
When the camera shutter is pressed, the camera looks for something white in the scene to use as a point of reference. Even if the other colors in the scene are dominating the white, the balance function will try to adjust that white in the scene to the same degree of white that we see it with our eyes. The remaining colors in the scene are then adjusted proportionate to the white. The result should be a pretty neutral tone image with all colors showing as they should.
Automatic white balance works pretty good the majority of time. However, there might be times when it might still produce an image with coloring that is off. An example would be a scene that lacks any white color so there is no point of reference.
Most cameras have white balance setings that can be changed to fit a particular scene. Try using your camera’s built in settings such as fluorescent, cloudy, daylight, or whatever might fit the scene you are about to shoot. These settings may vary from camera to camera, but hopefully you will find a setting that will work for you.
Some cameras will allow you to manually pre set your white balance to suit your needs. Take a look at the tutorial on my website about White Balance for a tip on using a white sheet of paper or neutral gray card to pre-set your white balance.
In closing, lets say you just want to shoot without having to worry about white balance. If your camera allows you to take images in the raw mode, just use that mode. It is very likely you will have the wrong tint in some of the images, but you can adjust the color later using an image correction application like Photoshop.
So now you know what White Balance is all about.
